How to Troubleshoot a Flashlight and Determine whether the Problem is Caused By the Switch or The LED Pill

-
The two main Parts in an LED Flashlight are : 1- Tail Cap Switch :      2- The LED Pil l (the thing that Houses the LED and Screws into the Flashlight Host)  :  in order to Determine which one of them is not working You'll need only : a Piece of Wire (20cm) and an 18650 Battery Connect them as Shown in the following Picture :  Connect one of the wire terminals to the Negative Side of the Battery and Connect the Other terminal of the wire on the Side of the Pill and then Touch the Positive terminal of the Battery to the Spring of the Pill If the LED turned on Then The Problem is Caused By the Switch, to Fix or Replace the  Flashlight Switch Click Here But if the Led didn't turn on then There is a Problem in the Pill, Either there is a Loose wire because of a bad Soldering Joint, or the Led is Burnt.  either way, it can be fixed easily! Good Luck! Best Regards Thulfiqar Ali ...
Read more

How to Reflow a Cree LED using only Soldering Iron and solder wire

-
how to reflow Cree LEDs on led Stars (MCPCB boards) without using solder paste or hot air station you will need 1- soldering Iron ( preferably 40 Watts and above) 2- solder wire 3- flux paste 4- third hand 5- tweezers (TS-15) 6- Digital multimeter 7- Safety glasses Step one: Place the LED on the PCB Holder and then use the soldering iron to heat up the MCPCB Board , once the flux starts to smoke remove the led from the board using the tweezers Step Two Melt a small amount of solder on the pads of the MCPCB board Step Three Add a small amount of flux on the back of the LED step four Heat up the Board and once the solder melts seat the LED in the Correct orientation, after seating the LED on the Pads Tap on its dome to remove the excess solder don't move the LED until the board cools down Done!
Read more

Youtube CEO list from 2005 to 2019

-
Youtube CEOs List from 2005 to 2019 : 1-   Chad Hurley ( American  )   :     2005 -  October 29, 2010 2-   Salar Kamangar (Iranian) :   October 29, 2010 -  February 5, 2014 3-   Susan Wojcicki ( Russian-Jewish)   :   February 5, 2014 - Current
